HD-430A Sheet Feeding Paper Carry Bag Machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Information
Properties and uses:
HD-430A Sheet fed Paper Bag machine is a fully automatic machine for the production of square bottom paper bags with folded top. The material could be Sheet paper or printed sheet paper/ Laminated Sheets only. It can produce variable sizes paper bags. The machine automatic paper fed from sheets, Automatic Die-cutting(creasing lines for folding), Bag tube forming, Bag bottom forming , bottom cardboard insertion & gluing, Bag bottom folding & gluing, Bag forming and final bag output, All steps are completed in-line.
HD-430A Sheet fed Paper Bag machine is a fully automatic machine for the production of square bottom paper bags with folded top. The material could be Sheet paper or printed sheet paper/ Laminated Sheets only. It can produce variable sizes paper bags. The machine automatic paper fed from sheets, Automatic Die-cutting(creasing lines for folding), Bag tube forming, Bag bottom forming , bottom cardboard insertion & gluing, Bag bottom folding & gluing, Bag forming and final bag output, All steps are completed in-line.
Technical Parameters
|
Machine Model |
HD-430A |
|
Min. Paper size |
545x350 mm |
|
Max. Paper size |
1225x600 mm |
|
Paper Thickness |
1. Kraft Paper 120-200g/㎡ |
|
Paper Bag Width |
180-430 mm |
|
Bag Tube Length |
350-600 mm |
|
Bag Bottom Width |
80-170 mm |
|
Bag Top fold Depth |
30-60 mm |
|
Speed |
40-70 Bags/min. |
|
Total Power |
20 KW |
|
Machine Weight |
10000 KG |
|
Machine Dimension (L*W*H) |
14500 x 2000 x 2100 mm |
|
Type of Glue |
(Cold & Hotmelt Glue) |
