FJ-800 Paper Roll Slitting Machine
FJ-800 Paper Roll Slitting Machine
description1
Zipper closure 1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout
Techincal Specificiation
Main Mechanical Configuration:

Main Body

  • Machine main configuration use casting iron and steel plate .
  • Main transmission roller use seamless steel tube after surface hardening and chromel and dynamic balance treatment.
  • Main transmission press roller is rubber roller.
  • Feeding roller is metal roller and rubber roller .
  • Main transmission and rewinding drive by synchronization wheel & belt.
  • The main press roller up and down is controlled by pneumatic.

Unwinding part

  • Unwinding device is independent ,it uses steel framed structure
  • Install one set of removable loading device . move guide rail use ABBA import element.
  • Chuck is 3 inches, controlled by hydraulic locking device
  • Loading device up and down controlled by hydraulic oil cylinder at left and right.
  • Unwind brake is 10kg brake , tension is controlled by manual .
  • One set of heavy duty LPC device .

Rewinding part

  • Machine with round knife device
  • Round knife shaft up and down is controlled by manual.
  • One rubber bent roller with manual adjustable direction
  • Rewinding shaft uses a air shaft with a 3 inches paper core
  • Rewinding tension is manual tension
  • Unloading uses removable way , loading by hydraulic lift .
  • 1 set of air tube and a waste blower
  • Rewind by 10kg clutch.

Electric part

  • Main inverter YASKAW 7.5KW
  • Main motor 7.5kw
  • Rewind tension is controlled by manual .
  • The functions with automatic reduce the speed and automatic stop.
  • The functions with indication at the end of material.
  • The functions with set reduce the speed advance and stop.
  • The functions with fault indication.
  • LPC limited stop automatically .
Technical Parameters

Machine Model

FJ-800

Max. rewinding diameter

1300mm

Max.unwinding diameter

1000mm

Mechanical speed

50m/min

Slitting Rewinding Width

100-500 mm

Rewind paper core

76mm

Unwind Paper core diameter

76mm

Weight

～3800㎏

Voltage

AC380V+N 50HZ

Total power

～11KW

EPC precision

+1mm
