WFD-450 Fully Automatic Sheet Fed Paper Bag With Handle Machine
description1
Zipper closure
1/5 zip athletic pullovers for men. Stretchy, lightweight, fast-drying
fabric for superior performance.
REGULAR FIT - US standard sizes. An athletic fit that sits close to the
body
for a wide range of motion, designed for optimal performance and all day
comfort.
FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them
in
place during workout
Information
Properties and uses:
It is suitable for producing high-quality paper bags for retail, gift packaging, garment, shoes or all luxury brands packaging. With its advanced technology and reliable performance, this sheet fed paper bag machine is an excellent investment for businesses looking to enhance their packaging capabilities.
It is fully automatic machine for the production of paper bags with paper twisted rope handle. The material could be Sheet paper or printed sheet paper.
This model is its ability to produce paper bags of different sizes and paste paper handle inline for completely paper bags without any manual process. The machine automatic paper fed from sheet, handle pasting line,top of bag folding, tube forming, bottom forming, bottom glue, bag forming and final bag output,or fold the top and punching holes without handle unit. All steps are completed in-line.
Three types of handle bags can be made on these type of machines.
It is suitable for producing high-quality paper bags for retail, gift packaging, garment, shoes or all luxury brands packaging. With its advanced technology and reliable performance, this sheet fed paper bag machine is an excellent investment for businesses looking to enhance their packaging capabilities.
It is fully automatic machine for the production of paper bags with paper twisted rope handle. The material could be Sheet paper or printed sheet paper.
This model is its ability to produce paper bags of different sizes and paste paper handle inline for completely paper bags without any manual process. The machine automatic paper fed from sheet, handle pasting line,top of bag folding, tube forming, bottom forming, bottom glue, bag forming and final bag output,or fold the top and punching holes without handle unit. All steps are completed in-line.
Three types of handle bags can be made on these type of machines.
Technical Parameters
|
Machine Model |
WFD-450 |
|
Min. Sheet Paper size |
625x 330mm(625x 280mm W/O handles) |
|
Max. Sheet Paper size |
1225 x 520mm(1025x 600mm W/O handles) |
|
Paper Thickness |
100-200gsm/㎡ (210-250gsm/㎡need to die cut) |
|
Paper Bag Width |
220-450 mm |
|
Paper Tube Length |
240-490 mm |
|
Bag Bottom Width |
80-170mm |
|
Bag Top fold Depth |
50mm(35)-60 mm |
|
Handle Patch Length |
190 mm |
|
Handle Patch Width |
40-55 mm |
|
Paper GSM for Handle patch |
120-200gsm |
|
Handle patch Roll Diameter |
￠1000 mm |
|
Paper Patch Roll Width |
80-110 mm |
|
Diameter of Twisted Rope |
4-6 mm |
|
Length of Twisted rope |
155-175 mm |
|
Speed |
50-60 Bags/min. |
|
Total Power |
28KW |
|
Machine Dimension |
16000 x 4800 x 3000mm |
|
(L x W x H) |
|
|
Type of Glue |
Cold & Hot melt Glue |
